| Brand | Yato |
| Entity responsible for this product in the EU | TOYA S.A.More |
| Series | GRF |
| Connecting elements type | nails |
| Connecting elements length | 22-45 mm |
| Connecting elements dimensions | 22-45x3.05x10.5 mm |
| Max. working pressure | 0.8 MPa |
| Recommended working pressure | 0.4-0.8 MPa |
| Air connection diameter (PT) | standard |
| Air supply hose inside diameter | 3/8" (9.5 mm) |
| Dispenser capacity | 120 szt. |
| Dimensions | 295x279x58 mm |
| Body material | aluminum |
| Handle material | rubber |
| Wire collated nail angle | 15 ˚ |
| Functions | sequential operating mode, side loading system |
| Dust cover | yes |
| Fuse | yes |
| Acoustic pressure | 94.2 ± 2.5 dB(A) |
| Acoustic power | 107.2 ± 2.5 dB(A) |
| Vibrations | 2.69 ± 0.1 m/s² |
| Weight | 2.59 kg |
| Application | upholstery, carpentry, finishing works |
| Symbol | YT-09220 |
A professional drum nailer provides precise, fast, and durable fastening of materials using nails. Created for demanding and intensive carpentry, assembly, and upholstery work, it also works well for light finishing tasks.
It has protection against accidental firing, a side loading system, and a dust cover. The sequential mode improves work efficiency, increasing installation productivity.
- fastener length: 22-45 mm
- nail wire joining angle: 15°
- fastener dimensions: 22-45 x 3.05 x 10.5 mm
- max. operating pressure: 0.8 MPa
- air inlet diameter: standard
- internal diameter of air supply hose: 3/8" (9.5 mm)
- 120-nail capacity magazine allows for longer uninterrupted work
- sequential mode function allows for controlled, rhythmic driving of fasteners, improving accuracy and increasing user safety
- safety fuse minimizes the risk of accidental tool activation
- dust cover increases tool lifespan and protects the mechanism inside under intensive use conditions
- side loading system facilitates and speeds up magazine refilling, which is particularly important for serial work
- aluminum body ensures high resistance to mechanical damage, while maintaining the device's low weight, especially appreciated during long hours of work
- anti-slip rubber handle provides a secure grip and reduces vibration transfer to the hand
- compact dimensions: 295 x 279 x 58 mm allow for easy maneuvering, even in hard-to-reach places
- weight: 2.59 kg
